Available Variants
12 variants available
| Max Pressure | Size (inch) | Article No | Description | Screws (Metric) | OR Type | Weight |
|---|---|---|---|---|---|---|
| 345 | 1/2" | SFS301D | Dimensions: B: 13 | C: 30,2 | D: 24 | F: 6,73 | - | 4075 | 0,55 |
| 345 | 3/4" | SFS302D | Dimensions: B: 19 | C: 38,1 | D: 32 | F: 6,73 | - | 4100 | 0,84 |
| 345 | 1" | SFS303D | Dimensions: B: 25 | C: 44,4 | D: 38 | F: 8,00 | - | 4131 | 1,21 |
| 276 | 1"1/4 | SFS304D | Dimensions: B: 32 | C: 50,8 | D: 43 | F: 8,00 | - | 4150 | 1,35 |
| 207 | 1"1/2 | SFS305D | Dimensions: B: 38 | C: 60,3 | D: 50 | F: 8,00 | - | 4187 | 1,65 |
| 207 | 2" | SFS306D | Dimensions: B: 50 | C: 71,4 | D: 62 | F: 9,53 | - | 4225 | 1,76 |
| 414 | - | SFS601D | Dimensions: B: 13 | C: 31,8 | D: 24 | F: 7,75 | - | 4075 | 0,56 |
| 414 | 3/4" | SFS602D | Dimensions: B: 19 | C: 41,3 | D: 32 | F: 8,76 | - | 4100 | 0,92 |
| 414 | 1" | SFS603D | Dimensions: B: 25 | C: 47,6 | D: 38 | F: 9,53 | - | 4131 | 1,25 |
| 414 | 1"1/4 | SFS604D | Dimensions: B: 32 | C: 54,0 | D: 44 | F: 10,29 | - | 4150 | 1,58 |
| 414 | 1"1/2 | SFS605D | Dimensions: B: 38 | C: 63,5 | D: 51 | F: 12,57 | - | 4187 | 2,12 |
| 414 | 2" | SFS606D | Dimensions: B: 50 | C: 79,4 | D: 67 | F: 12,57 | - | 4225 | 3,26 |
